8.4" SGVA Sunlight Readable Industrial Display
eXTreme (XT) Series by Seatronx is a ruggedized IP68 all weatherproof series of displays for extremely harsh and demanding environments where EXTREME protection is very important. The XT Series is a slim compact, lightweight design, the XT SERIES housings are made from a milled aluminum alloy to create a ruggedized enclosure along with the IP68 sealed connectors to meet the demand of IP68 applications.
XT Series by Seatronx are multipurpose displays that feature the unmatched quality and reliability that you can depend on. These displays are ideal for rugged applications such as military, industrial and marine environments.
Features
- Mounting - VESA, Flush, Panel, U- Bracket mount (optional)
- Housing - Machined Aluminum alloy, Black powder coated
- Power Conditioning - Protected against Internal short circuit, load dump, over-voltage, reverse polarity
- Soft-touch dimming adjustment to any light (0 nits to full brightness)
- Accepts wide range resolution VGA to UXGA
- High ambient contrast ratio
Technical Specifications:
- Screen Size - 8.4"
- Resolution - SVGA (800×600)
- View Angle - 160° (H) x 160° (V)
- Contrast Ratio - 900:1
- Dimming Ratio - 1000:1
- Power Consumption - 18W
- IP Rating - IP68 (NEMA 6 Submersible)
- Operating Temperature - -10°C to 60°C (-14°F to 140°F)
- Storage Temperature - -30°C to 80°C (-40°F to 176°F)
Specifications:
- AC/DC: DC
- Resolution (VxH): 800x600
- Screen Size: 8.4"
Brochure (pdf)
